PowerMeasuringModule PMM
35,0(
6
46
Revision 13 EN - 02/2023
A
B
Status
Measurement
running=1
Status
Measurement
finished=1
Status
Irradiation failure=1
Shutter Acknowledge?
Status
Shutter is closed=1?
Status
Shutter error=1?
Finish
Read results
Check measured integration time
Command do close shutter=1
Trigger Laser Pulse
Command do close shutter=0
Status
waiting period
expired?
Command do reset=1
Command do reset=0
PMM idle?
