PowerMeasuringModule PMM

35,0(6

Revision 13 EN - 02/2023

18 Dimensions

PRIMES

View X

190

100

88.5

175

226.5

245.5

200

134.5

Ø 49

Ø 6.6

Dimensions in mm
