9.2 General flow diagram of a PMM measurement
Excess temperature
flag?
PMM idle?
PMM idle?
Shutter open = 1?
Start Acknowledge = 1?
Status
Shutter is open = 1?
Status
Shutter error = 1?
PMM ready = 1?
Start PMM Measurement
Command do_reset = 1
Command do_reset = 0
Set "Start measurement" = 1
Command do open shutter = 1
Command do open shutter = 0
Reset "Start measurement" = 0
Shutter Acknowledge?
A
B
