If applicable, specimens found reactive in the primary assay may be run in individual
Discriminatory Assays to determine if they are reactive for one of the viruses being
assayed or any combination of viruses.
4. After the luminometer reads the amplicon signal, the system dispenses Deactivation Fluid
to destroy any amplicon present in the MTU, aspirates the liquid, and discards the MTU.
The Discriminatory Assay steps are identical to the primary assay steps except that
Discriminatory Probe Reagents specific to a single virus are used in place of the primary assay
Probe Reagent.
Specifications
Physical Specifications
Table 1.6 Size and Weight Specifications
Table 1.7 Clearance Specifications
Environment
Table 1.8 Environmental Requirements
Table 1.9 Environmental Output
Component Dimensions (W x D x H) Weight
PROCLEIX
®
TIGRIS
System Analyzer
69 x 36 x 72 in
(175.3 x 91.4 x 183 cm)
1291 pounds (581 kg)
Vacuum Pump
17 x 11.8 x 17.4 in
(43 x 30 x 44 cm)
55 pounds (25 kg)
Component Minimum clearance required
PROCLEIX TIGRIS System
Analyzer (Overall space required
is: 117 x 60 x 96 in (297 x 152 x
244 cm, W x D x H)
24 in (61 cm) vertical clearance
24 in (61 cm) around left side and back
24 in (61 cm) accessible on the right side
36 in (91.4 cm) at front of analyzer
Computer Workstation 24 in (61 cm) clearance in front
Ambient Temperature 15 to 25° C
Humidity 20-85%
Shock and Vibration Compliance with IEC 68-2-6, 7.
Heat Dissipation
773 W (2637 BTU/Hour) during steady operation
(Conversion is 2637 x .293= 773 W)
Noise Output Compliant with EN61010-1.
Drain Output None—Waste fluids drain to removable containers.
