5-3
VIBXPERT 11.2010
Entering the normalization parameters
Before the shock pulse measurement starts, the normalization screen
appears:
• Select the type of normalization:
N
O NORMALIZATION: Shock pulse value specified in dBsv.
M
ANUAL: RPM is entered manually before the shock pulse measure-
ment.
E
XTERNAL: RPM is measured with an RPM sensor before the shock
pulse measurement.
• Enter the dBa value in the number editor (P. 6-1) if it is known.
Otherwise, carry out a normalization adaptation (set dBa to '0', see
previous section).
• Enter the diameter of the bearing inner race.
• If the normalization type is set to 'manual', enter the RPM (see
below).
• To start the shock pulse measurement, click on 'OK'.
Shock pulse - Normalization
Measurement tasks
