5-5
VIBXPERT 11.2010
Measurement tasks
Temperature measurement
For temperature measurements thermocouple type K sensors such as
the VIB 8.608 handheld probe or the VIB 8.607-1.5 sensor with
magnetic holder can be used.
Tips for measuring
- Hold the sensor at the measurement location until the sensor has
recorded the temperature of the measurement object.
- If the values vary, repeat the measurement or increase the number
of averages in the measurement setup.
- VIBXPERT does not carry out any sensor detection on the
measurement channel for temperature. If the results are not
correct, check the connection and the sensor cable.
Measurement range:
VIB 8.608: -50°C to 500°C
VIB 8.607: -50°C to 240°C
Hand-held temperature probe -
VIB 8.608
Magnetic temperature probe -
VIB 8.607-1,5
BA
R
R
F
E
S
C
M
E
N
U
H
E
L
P
Trigger stand
(VIB 6.632)
Sensor with magnetic holder
(VIB 6.142R + VIB 3.420)
Reflective tape
(VIB 3.306)
Laser trigger sensor
(VIB 6.631)
Trigger cable
(VIB 5.432-2.9)
Typical installation for a vibration
measurement with simultaneous
recording of the rotational speed.
Temperature probes
(Type K thermocouple, technical data
are given in the sensor catalog)
