3-20
VIBXPERT 11.2010
Creating a new setup (M)
You can only create a new setup for the measurement, evaluation or
rpm for user-defined measurement tasks. You can also create a new
sensor setup for measurement tasks preset at the factory.
How to create a new setup:
• Open the 'Task Manager' (see below and previous page).
• Select a user-defined measurement task.
• Click on the pulldown menu where the new setup should be
created.
• Press the MENU key and click on 'New' (see below).
• Enter a name in the text editor.
• Then set up the Setup parameters:
- Press the MENU key.
- Click on 'Edit'.
- Change the parameters as required:
see sections A to D on the following pages.
• To save, press the MENU key and click on 'OK'.
How to review the setup parameters:
• Open the 'Task Manager'
• Select the setup in the respective pulldown menu.
• Press the MENU key, and click on 'Show'.
In which measurement task was the setup already used?
• Open the 'Measurement Task Manager'.
• Select the required setup.
• Press the MENU key and click on 'Use'.
Options
y
M = in Multimode only
Left:
Open the Task Manager
Right:
Create a new setup
