3-27
VIBXPERT 11.2010
Signal sensitivity on analog output/headphones
The analog output is activated and configured in the device setup
(see p. 2-28). To adjust the sensitivity of the analog output, proceed
as follows:
• Press the MENU key in the measurement screen.
• Select ‘Analog Out’ / ‘<Sensitivity>’ and set the desired sensitivi-
ty.
For 2-channel measurements, you can also select the channel
whose signal is to be output on the analog output (see below).
Analog signal output
- Controlling signal sensitivity
- Selecting a measurement channel (2-
channel measurement)
