3-36
VIBXPERT 11.2010
Recording
Recording
With the ‘Recording’* function, you can perform measurements
dependent on time or rotational speed. For example, this method can
be used to record measurement values under certain operating
conditions (= rpm range) or at fixed time intervals.
Availability and restrictions
Recording is available in 'Multimode' for every measurement, with
the following exceptions:
-C
OASTDOWN CURVE
-IMPACT TEST
-TIME WAVEFORM RECORDER
-PHASE - CROSS CHANNEL
Restrictions also apply to the following measurements:
-S
PECTRUM: Averaging is not possible for rpm-controlled recordings.
-T
IME WAVEFORM: The 'time sychronous' averaging type is not
permissible.
-M
ULTI MEASUREMENT TASKS: rpm-controlled recording is not possible.
-S
HOCK PULSE MEASUREMENT (ROLLER BEARING CONDITION): rpm-controlled
recording is only possible without normalization.
Configuration
• Click on 'Multimode' in the start screen.
• Select the measurement for which you want to set up recording.
• Press the MENU key and click on 'Recording' (see below).
* Firmware module ‘Recording’ (VIB
5.385) must be registered.
Opening the recording
configuration window
