3-17
VIBXPERT 11.2010
Options
Options before, during and after a measurement
In addition to the information given in the previous sections, the
options for the measurement are described here.
Aborting a measurement
• Press the ESC key during the measurement.
Repeating a measurement
• In the results screen, press the joystick again, or ...
• Press the MENU key in the results screen and click on 'Remeasure'.
Saving a result
Route / Machine template:
• After the measurement confirm the ‘Save?’ prompt. If the ‘Automa-
tic save’ option is activated, the result is automatically saved (see
P. 2-18).
For measurement tasks that have already been measured, the
current result can be appended to the saved measurement data or
can overwrite them.
Multimode:
• Press the MENU key after a measurement and click on ‘Save’ (see
P. 3-4). In the case of a trend, the result is saved in the
corresponding existing data set (select ‘Append’, see P. 3-29).
Changing the measurement channel
Multimode:
• Highlight the measurement type in the selection screen.
• Press the MENU key, and click on 'Task manager'.
• Click on the 'Measurement Channel' field to activate it (see below)
and then select the measurement channel (A, B , A/B*).
• To save the change, press the MENU key and click on 'OK'.
Sensor
* Channel A/B:
The overall value, spectrum and time
signal can be measured on each of the
two channels simultaneously if the 2-
channel module is registered.
E
S
C
M
E
N
U
Left:
Repeat measurement
Right:
Change meas. channel / sensor
in the task manager
