PRÜFTECHNIK VIB 5.300 Series User Manual

3-16
VIBXPERT 11.2010
Measurement - Machine template
The template then appears, which – like a route – is displayed as a
tree structure or in the form of a list* (see section ‘Route’). The
following steps are identical to those in the ‘Route’ section:
• Click on the measurement location.
• Select the measurement task, and connect the sensor specified in
the info field.
• Click on the measurement task to start the measurement.
• Select the next measurement task and start the measurement.
Once all measurement tasks have been completed, the following
message appears: 'All measurements on the machine carried out!'
* not in the case of templates for
production tests
