VIBXPERT 11.2010
Foreword
Congratulations! And thank you for selecting the VIBXPERT FFT data
collector and signal analyzer*. This newly developed measurement
device is not just the ideal companion for your routine measurement
round, but also a reliable on-site aid for recording and analyzing
complex machine signals.
VIBXPERT records all types of machine vibrations, bearing conditions
as well as process and visual inspection data, and transfers this
information to the OMNITREND maintenance software for evalua-
tion, archiving and documentation.
The combination of its extensive range of features and easy operation
makes VIBXPERT the effective choice for a wide range of applications:
• High measurement accuracy and high-speed data collection
• Operating modes:
'Route' for routine data collection for condition-based mainte-
nance,
'Multimode' for individual measurements for machine diagnosis
'Balancing' in one or two planes (optional).
'Machine templates' for recurrent measurement tasks within the
scope of acceptance or service measurements
• Almost every type of sensor can be connected
• One or two measurement channels (analog);
Upgrade to 2-channel device at any time via password.
• Intrinsically safe version available.
Hardware
• Two synchronous measurement channels for diagnosis of complex
measurements (e.g. shaft vibration).
• Unlimited storage capacity (Standard: 2 GB CompactFlash).
• Three alarm LEDs (red-yellow-green) indicate if thresholds have
been exceeded (based on ISO standards). A blue LED lights up if
everything is OK.
• Daylight sensor controls keyboard illumination
• Dustproof and splashproof (IP65) - ideal for use in demanding
industrial environments
• Connector technology compatible to VIBSCANNER (same cable)
• Connector for NiCrNi thermocouples
• Connector for headphones
Data collection and data analysis
• Overall values
- Vibration acceleration, velocity, displacement
- Current & voltage (process parameters)
- Shock pulse (bearing condition)
- Temperature
- RPM
• Signals
- Frequency-based and order-based data collection
- Amplitude, envelope, order spectra
* Also referred to as 'VIBXPERT' and
'device' in these operating instructions.
