Chapter 5: Configuration
Keyboard Properties
96 WORKABOUT PRO G2 Hand-Held With Windows Embedded CE 5.0 User Manual
Adding And Changing Unicode Values
Important: Changes to Unicode mappings are not saved until you exit the
Keyboard Properties dialog box.
• Choose the Add/Change button.
Figure 5.4 Adding And Change Unicode Values
• Highlight a value in the Unicode mapping list. In the sample screen above,
a value will be assigned to virtual key 0 (VK 0).
• Position the cursor in the Unicode Mapping
field, and type a Unicode
value for the highlighted key.
Note: To add a shifted state, [SHIFT] and/or [CTRL], press [TAB] to position
the cursor in the checkbox next to ‘SHIFT Pressed’ and/or ‘CTRL
Pressed’. Press [SPACE] to select the shift state you want to assign.
Removing Unicode Values
•In the Unicode Mapping tab, highlight the item you want to delete, and
choose the Remove button.
