Tether Port Pinout
A-2 WORKABOUT PRO Hand-Held With Windows Embedded CE 5.0 User Manual
A.2 Tether Port Pinout
PIN # Signal Name
1Ground
2 USB Host Data Plus, For connecting USB Devices
3 USB Host Data Minus, For connecting USB Devices
4 USB Host Power, for powering USB devices (5V, 100mA Max)
5 TX Data } TX Data and RX Data are only available on terminals with no
internal Bluetooth
6RX Data }
7 Tether Detect, determines if a device is attached to the Tether port
8 DC Power In, for supplying power to WORKABOUT PRO / charging
battery (5V, 3A)
9 DC Power In, for supplying power to WORKABOUT PRO / charging
battery (5V, 3A)
10 DC Power In, for supplying power to WORKABOUT PRO / charging
battery (5V, 3A)
11 Not used.
12 Not used.
13 Not used.
14 Not used.
15 Not used.
16 Ground
17 Ground
18 Ground
