Psion Teklogix Workabout PRO G2 - Appendix A: Port Pinouts; LIF (Low Insertion Force) Port Pinout

WORKABOUT PRO Hand-Held With Windows Embedded CE 5.0 User Manual A-1
APPENDIX A
PORT PINOUTS
A.1 LIF (Low Insertion Force) Port Pinout
PIN # Signal Name
1 Ground
2 Ground
3 USB Host Data Plus, For connecting USB devices
4 USB Host Data Minus, For connecting USB Devices
5 USB Host Power, for powering USB devices (5V, 100mA Max)
6 DC Power in, for supplying power to WORKABOUT PRO / charging
battery (5V, 3A)
7 DC Power in, for supplying power to WORKABOUT PRO / charging
battery (5V, 3A)
8 LIF Detect, determines if a device is attached to the LIF
9 USB Device Data Minus, for operating the WORKABOUT PRO as a
USB device
10 USB Device Data Plus, for operating the WORKABOUT PRO as a
USB device
11 Ground
12 Ground
