Chapter 7: Specifications
EV15 Imager Decode Zone
248 WORKABOUT PRO G2 Hand-Held With Windows Embedded CE 5.0 User Manual
7.3.2.1 EV15 Imager Decode Zone
7.3.3 HHP5180 Imager
Reading Distance Up to 90cm (35 in)
Symbologies
UPC (E&A), EAN, RSS, Code 39, Code 128,
UCC/EAN 128, ISBN, ISBT, Interleaved,
Matrix, Industrial and Standard 2 of 5, Codabar,
Code 93/93i, Code 11, MSI, Plessey, Telepen,
PDF417, Micro PDF417
Ambient Light
Works in any lighting conditions, from 0 to
100,000 lux
Shock 2000G, 0.7ms, half sinus, 3 axes
Vibration 50G r.m.s
0 Lux to 100,000 Lux
Minimum range Maximum range
Mil Size Inches Inches
52.5 7
10 3 14
UPC
214.5
20 2.5 22
40 3 35.5
High quality symbols in normal room light.
Parameter HHP5180
Image Sensor 752 X 480 CMOS sensor
Motion Tolerance 4 in. (10.2cm) per second
Rotational Sensitivity 360°
Viewing Angle ±40°
Ambient Light Total darkness to 100,000 lux (full sunlight)
Illumination LEDs 626nm ±30nm
Aiming:
LEDs: 526nm ±30nm
Laser: 650nm ±10nm
Parameter EV15
