WORKABOUT PRO G2 Hand-Held With Windows Embedded CE 5.0 User Manual 247
Chapter 7: Specifications
SE 1223ALR Decode Zone
7.3.1.3 SE 1223ALR Decode Zone
7.3.1.4 SE 955HP Decode Zone
7.3.1 EV15 Imager Specifications
4,844 Lux to 86,112 Lux
Minimum
range
Width of field
Maximum
range
Width of field
Mil Size Inches Inches Inches Inches
UPC
19 2 39 4
15 20 2 50 6
30 33 4 98 11
55 27 2 115 12
70 reflective 114 12 250 28
100 reflective 125 14 360 41
High quality symbols in normal room light.
Decode Zone Typical
4 mil 1.0 in. - 5.5 in. / 2.54 cm - 13.97 cm
5 mil 1.25 in. - 8 in. / 3.18 cm - 20.32 cm
7.5 mil 1.5 in. - 13.25 in. / 3.81 cm - 33.66 cm
10 mil 1.5 in. - 17.5 in. / 3.81 cm - 44.45 cm
UPC 100% 1.5 in. - 23.5 in. / 3.81 cm - 59.69 cm
15 mil 1.5 in. - 29.5 in. / 3.81 cm - 74.93 cm
20 mil 1.75 in. - 35.5 in. / 4.45 cm - 90.17 cm
40 mil * - 40 in. / * - 101.6 cm
55 mil * - 55 in. / * - 139.7 cm
* dependent on width of bar code
Parameter EV15
Light Source 617nm Highly Visible LED
Scan Angle 40º
Minimum Print Contrast Minimum 25%
Min x. Dimension 0.1 mm (4 mils)
