PCX SMS AND PCX 256 SYSTEM MANUAL
RINS871-3 Page: 119
17.5 STU/ATE and RS232 Connections
NC1
COMMS PGMS
TAMPER
RESET
ENGINEER
KEYPAD
RS232
BATTERY
CONNECT
----------------SAB----------------
COMMUNICATION CARD
EXPANSION CARD SLOT
AUX+
C1
SPK
NO1
NC2
A
-1 B-1 A B
C2
TR
NO2
B-
B+
F2
F3 F4 F5
F1
PGMS
BELL
AUX
BUS
BATTERY

STU/ATE
Output Pins
RS232
Connector
17.5.1 RS232 Connector
The RS232 connector is used to connect an RS232 lead via a PC/Laptop. This enables the engineer to
upload/download information from the panel using the PCX UDL Software.
Please contact Pyronix or your local distributor regarding the PCX software.
17.5.2 Connecting the Communication Loom
MAKE SURE THE COMMUNICATION LOOM IS CONNECTED AS SHOWN BELOW:
NC1
COMMS PGMS
TAMPER
RESET
ENGINEER
KEYPAD
RS232
BATTERY
CONNECT
----------------SAB----------------
COMMUNICATION CARD
EXPANSION CARD SLOT
AUX+
C1
SPK
NO1
NC2
A
-1 B-1 A B
C2
TR
NO2
B-
B+
F2
F3 F4 F5
F1
PGMS
BELL
AUX
BUS
BATTERY

MAKE SURE YOU
CONNECT THE LOOM
THE CORRECT WAY.
THE WIRE
SHOULD BE NEAREST
TO THE DIGI MODEM
AND MSX CARD SLOTS
BLACK
CONNECT THE LOOM
ON THE PINS
BLACK
PURPLE
