5.4 Devices Technical Specification
LCD KEYPAD (PCX-LCD/UK)
Supply Voltage 13.8V (9-16V range)
Supply Current
Min brightness setting 80mA
Max brightness setting 150mA
Operating Temperature 0 to 50°C
Dimension 139 x 127 x 29mm
Output (PGM) Current 100mA
EXTERNAL TAG READER (PCX-PROX/EXT)
Supply Voltage 13.8V (9-16V range)
Supply Current Max. 90mA @ 13.8V
Operating Temperature -10 to +50°C
Dimensions 85 x 85 x 21mm
INTERNAL TAG READER (PCX-PROX/INT)
Supply Voltage 10.5 to 15V
Supply Current 60mA
Operating Temperature -10°C to +40°C
Dimension 100 x 70 x 30mm
Output (PGM) Current 100mA
Supply Voltage 10.5 to 15V
REMOTE INPUT EXPANDER (PCX-RIX2)
Supply Voltage 10.5 to 15V
Supply Current 40mA
Operating Temperature -10°C to +40°C
Dimension 100 x 70 x 30mm
Output (PGM) Current 500mA
REMOTE INPUT EXPANDER (PCX-RIX8)
Supply Voltage 10.5V to 15V
Quiescent Current 30mA
Dimensions 210 x 130 x 50 mm
REMOTE INPUT EXPANDER (PCX-RIX8+)
Supply Voltage 10.5 to 15V
Supply Current 40mA
Operating Temperature -10°C to +40°C
Dimension 100 x 70 x 30mm
Output (PGM) Current 500mA
Supply Voltage 10.5 to 15V
REMOTE OUTPUT EXPANDER (PCX-ROX16R)
Supply Voltage 10.5V to 15V
Supply Current 30mA (no relays active)
Supply Current 340mA (all relays active)
Max Switching Voltage 24A
Max Switching Current 3A
POWER SUPPLIES FOR RIXs and ROXs
Power Supply 2.5A
Mains (220-240V AC) 50Hz 150mA
Mains Fuse Slow Blow (T) 250mA
Output 13.75V 1.0A continuous
Battery Fuse 3.15A Quick Blow
Output Fuse 1.25A Quick Blow
5.4.1 Lightning Protection
The inbuilt lightning protection is provided by fast acting gas discharge tubes.
The quality of the protection is protected upon the low impedance telecoms earth being connected.
5.4.2 Code Guessing
When the PCX is armed, an intruder may try to ‘guess’ the user code to disarm the system, the PCX
incorporates a feature that stops this; If 30 or more invalid key presses are input, or 6 invalid tags are
presented at the keypad, the keypad will disable or ‘freeze’ for 90 seconds. It will then subsequently ‘freeze’
after 7 further invalid key presses or another invalid tag is presented.
After the lock up time has timed out, a valid user code/tag may be presented and the system will disarm.
‘Code Guessing’ will be visible on the keypad. To clear this press P.
