PCX SMS AND PCX 256 SYSTEM MANUAL
Page: 14 RINS871-3
CHAPTER 4: SYSTEM OVERVIEW
This manual supports the following panels: PCX 26/SMS and the PCX 256.
4.1 PCX 26/SMS Input Information
The PCX 26/SMS consists of the following components:
¾ PCX 8 Input Expander
¾ PCX LCD Keypad
Location Inputs Location Inputs
Control Panel
1 – 8
RIX 01
17 – 24
RIX 00
9 – 16
Keypad/Reader 00
25 – 26
4.2 PCX 256 Input Information
The PCX 256 consists of the following components:
¾ MSX Card
¾ PCX 8 Input Expander
¾ PCX LCD Keypad
Location Inputs Location Inputs
Control Panel
1 – 8
RIX 18
153 – 160
RIX 00
9 – 16
RIX 19
161 – 168
RIX 01
17 – 24
RIX 20
169 – 176
RIX 02
25 – 32
RIX 21
177 – 184
RIX 03
33 – 40
RIX 22
185 – 192
RIX 04
41 – 48
RIX 23
193 – 200
RIX 05
49 – 56
RIX 24
201 – 208
RIX 06
57 – 64
RIX 25
209 – 216
RIX 07
65 – 72
RIX 26
217 – 224
RIX 08
73 – 80
RIX 27
225 – 232
RIX 09
81 – 88
RIX 28
233 – 240
RIX 10
89 – 96
Keypad/Reader 00
241 – 242
RIX 11
97 – 104
Keypad/Reader 01
243 – 244
RIX 12
105 – 112
Keypad/Reader 02
245 – 246
RIX 13
113 – 120
Keypad/Reader 03
247 – 248
RIX 14
121 – 128
Keypad/Reader 04
249 – 250
RIX 15
129 – 136
Keypad/Reader 05
250 – 252
RIX 16
137 – 144
Keypad/Reader 06
253 – 254
RIX 17
145 – 152
Keypad/Reader 07
255 – 256
