PCX SMS AND PCX 256 SYSTEM MANUAL
Page: 48 RINS871-3
13.5 Install RIX
Any Remote Input Expanders installed on the PCX system must be enabled by the ‘Install RIX’ function.
Please see the table on page Error! Bookmark not defined. on how many RIX’s you can install on your
system, for connection details please see Page: 125.
Visual Keypad Programming Procedure
INSTALL RIX
Install RIX
Using the mand Pkeys, scroll to ‘INSTALL RIX?’
Press the Okey
RIX Address
Please select the address for the RIX you are
installing and press the Okey
RIX Installed?
Enable/Disable the RIX that you have installed.
Enter : for NO
Enter : for YES
Press the Okey
RIX Address
Repeat for additional RIX’s or press the Pkey.
You will be returned to the Engineer Menu.
