PCX SMS AND PCX 256 SYSTEM MANUAL
RINS871-3 Page: 15
4.3 System Overview
4.3.1 Inputs
Inputs on Main Board
PCX 26/SMS /
PCX 256
8 fully programmable inputs
Input Expander PCX-RIX
PCX 26/SMS /
PCX 256
8 fully programmable inputs
PCX 26/SMS 26 inputs using 2 x PCX RIXs & 1 PCX Keypad
Maximum Inputs Capacity
PCX 256 256 inputs using 29 x PCX RIXs & 8 PCX Keypads
Input Configurations
PCX 26/SMS /
PCX 256
DEOL, SEOL
PCX 26/SMS Digi Modem Card
Panel Additions/Expansion
PCX 256 Digi Modem Card, Expansion Card
Input Types PCX 26/SMS
Unused, Fire, Gas, HU, Silent HU, Tamper, Immediate,
Entry/Exit, Access, A (Part EE), EE (Part A), PTS,
Switcher, 24 Hour, Fault, Closure Supervision, Keyswitch
Latched, Entry Shock Input, Keyswitch Pulsed
PCX 256
Unused, Fire, Gas, HU, Silent HU, Tamper, Immediate,
Entry/Exit, Access, A (Part EE), EE (Part A), PTS,
Switcher, 24 Hour, Sub Part Control, Fault, Closure
Supervision, Shunt Input, Disarm Input, Keyswitch
Latched, Entry Shock Input, Keyswitch Pulsed
PCX 26/SMS
Chime, Omittable, Double Knock, Dual Trip, Normally
Open, Confirm Group.
Input Attributes
PCX 256
Chime, Omittable, Double Knock, Dual Trip, Normally
Open, Monitor Activity, Special Logged, Paired Input,
Confirm Group.
4.3.2 Programmable Outputs (PGM)
PGM Outputs On-Board PCX 26/SMS / 256
PGM1, PGM2: Relay (NC,C, NO), Speaker Output,
PGM4, PGM5: Transistor (Active High, Low)
Output Expander PCX 26/SMS / 256
PCX Remote Output Expander 16 Way Relay Outputs.
(PCXROX16R or PCXROX16R/PSU)
PCX 26/SMS
20 (4 on board + 1 ROX)
Note: PGMs also on RKPs, RIXs and Readers.
Maximum PGM Outputs
PCX 256
132 (4 on board + 8 ROXs)
Note: PGMs also on RKPs, RIXs and Readers.
PGM
Types
PCX
26/SMS
Not Used, Fire, Hold Up Any, Intruder Any, Misoperation Any (Abort), Confirmed
Any, Tamper Any, Duress, HU Device Any, Gas, Arm Fail, Entry Deviation,
Secure Intruder Any, Bell Any, Strobe Any, Omit Rearm Any, Unconfirmed Any,
Exit Starts Any, Final Arm Any, Strobe Set Fail, Keyswitch Unset, Entry/Exit,
Lights, Reset 1 (Viper Reset), Reset 2 (Viper Arm/Disarm), PIR Latch 1, PIR
Latch 2, Mains Good, Follow Test, Off During Test, Telephone Line Fault, AC
Fail, Battery Faults, Low Volts, Global Fault 1, Global Fault 2, Guard Code
Used, Engineer Access, Initialise Digi, Test ATS.
