PCX SMS AND PCX 256 SYSTEM MANUAL
Page: 56 RINS871-3
Input Type
Select the shunt input type (type 18)
Shunt Inputs
If you would like to select the shunt inputs for the
selected input press the Okey.
Enter the inputs you would like in the shunt list, after
each one press the Okey. Each input selected will
scroll on the display on the bottom line.
If the input you have selected doesn’t appear, make
sure that input is programmed correctly (Intruder,
Tamper, 24Hr or Access).
Once they have all been entered press the Pkey,
and press the Pkey again.
Input Partition
Enter the partitions/level arms you would like the input
to operate in (To select level arming instead of
partitions please refer to Site Options “Use Level
Arming”, see page: 84).
Example shows the PCX 256 system display.
Please note the primary partitions are A, B, C and D.
Press the Okey.
For partition arming systems only:
Enter : for Any
Enter : for All
Press the Okey
Input Attributes
Press the O key to select any attributes for the input
(for details on each attribute see page: 51)
