Matrix 832 / 832+ / 424
Page 54 RINS428-5
Armed Message
This message can be programmed by the installer to display text on the LCD display while the control panel is
in armed mode, and the keypad is configured as a private keypad. It is possible to choose a message to be
displayed from “LCD Keypad Text 1”. This can be a message such as ARMED, SERVICE TEL NUMBER,
COMPANY NAME and so on.
RKP Controlled Output Text
This message can be programmed by the installer to display text in connection with the available user option
to activate a PGM output from the keypad. This can be message such as OPEN DOOR, RESET
DETECTORS, ACTIVATE LIGHTS and so on.
Language Number
Number 000 is English. To allocate other languages available with this LCD version choose a language from
the language list. It is the responsibility of the Installer to make sure that the chosen language is available in
that version of keypad.
LCD Keypad Text 1
There are 26 text labels available, the text of which can be freely programmed and displayed on any of the 4
LCD keypads used by the system.
LCD Keypad Text 2
This option contains text labels that can be displayed on Engineer Mode entry.
LCD Keypads & Proximity Readers
Active in Partition
This enables keypads/proximity readers 1, 2, 3 and 4 to be allocated to different partitions. It is possible to
allocate keypads/proximity readers to 1 or more partitions. If allocated to one partition the keypad / reader will
operate and display system information only within this partition.
Private/Public
This option enables the visual information on a keypad to be programmed as private or public. If private the
system status will only be shown while the panel is being armed. If public then the system status will be
shown in any state of the panel.
Brightness
This option allows the brightness of individual keypads to be adjusted to different levels. By sliding the
brightness handle on the PC screen to the left the brightness will decrease. By sliding the brightness handle
on the PC screen to the right the brightness will increase.
Volume
This option allows the volume of individual keypads to be adjusted to different levels. By sliding the volume
handle on the PC screen to the left the volume will decrease. By sliding the volume handle on the PC screen
to the right the volume will increase.
Contrast
This option allows the LCD keypad display contrast to be adjusted. The Factory default is adequate for most
situations. Installations in warmer or cooler environments may require this setting to be adjusted for optimum
readability.
NOTE: The LCD contrast can be adjusted such that it is unreadable, care must be taken so this does
not occur.
NOTE: See user guide for the procedure to adjust brightness and volume from the keypad.
