882 Video Test Instrument User Guide (Rev A.35) 687
D Format Reference
Topics in this appendix:
• Formats by type
SDTV Formats
Format
Active
(HxV) Scan
Horizontal
Rate (kHz)
Vertical
Rate (Hz)
Pixel
Rate (MHz)
480i 720 x 480 Interlace 15.734 59.940 13.500
480i# 720 x 480 Interlace 15.734 59.940 12.272727
480i#KA 720 x 480 Interlace 15.734 59.940 12.272727
480i2x_1 720 x 480 Interlace 62.937 239.760 53.999968
480i2x_2 720 x 480 Interlace 63.000 240.000 54.054
480i2x29 720 x 480 Interlace 15.734 59.940 13.500
480i2x30 720 x 480 Interlace 15.750 60.000 13.5135
480i2x59 720 x 480 Interlace 31.469 119.880 27.000
480i2x60 720 x 480 Interlace 31.500 120.000 27.027
480i2xL1 720 x 480 Interlace 15.734 59.940 13.500
480i2xL2 720 x 480 Interlace 15.750 60.000 13.5135
480i2xL3 720 x 480 Interlace 31.469 119.880 26.999984
480i2xL4 720 x 480 Interlace 31.500 120.000 27.027
480i2xL5 720 x 480 Interlace 62.937 239.760 53.999968
480i2xL6 720 x 480 Interlace 63.000 240.000 54.054
480i2xS1 720 x 480 Interlace 15.734 59.940 13.500
480i2xS2 720 x 480 Interlace 15.750 60.000 13.513500
480i2xS3 720 x 480 Interlace 31.469 119.880 26.999984
480i2xS4 720 x 480 Interlace 31.500 120.000 27.027
480i2xS5 720 x 480 Interlace 62.937 239.760 53.999968
480i2xS6 720 x 480 Interlace 63.000 240.000 54.054
480i4x29 2880 x 480 Interlace 15.734 59.940 54.000
480i4x30 2880 x 480 Interlace 15.750 60.000 54.054
480i4xL1 2880 x 480 Interlace 15.734 59.940 54.000
480i4xL2 2880 x 480 Interlace 15.750 60.000 54.054
480i4xS1 2880 x 480 Interlace 15.734 59.940 54.000
480i4xS2 2880 x 480 Interlace 15.750 60.000 54.054
480iLH 720 x 480 Interlace 15.734 59.940 13.500
480iSH 720 x 480 Interlace 15.734 59.940 13.500
480iWH 960 x 480 Interlace 15.734 59.940 18.000
