688 Appendix D Format Reference
480p# 640 x 480 Interlace 31.469 59.940 24.545454
480p#KA 640 x 480 Progressive 31.469 59.940 24.545454
480p119 720 x 480 Progressive 62.937 119.880 54.000
480p119L 720 x 480 Progressive 62.937 119.880 54.000
480p119S 720 x 480 Progressive 62.937 119.880 54.000
480p120 720 x 480 Progressive 63.000 120.000 54.054
480p120L 720 x 480 Progressive 63.000 120.000 54.054
480p120S 720 x 480 Progressive 63.000 120.000 54.054
480p239 720 x 480 Progressive 125.874 239.760 107.999992
480p239L 720 x 480 Progressive 125.874 239.760 107.999992
480p239S 720 x 480 Progressive 125.874 239.760 107.999992
480p240 720 x 480 Progressive 126.000 240.000 108.108
480p240L 720 x 480 Progressive 126.000 240.000 108.108
480p240S 720 x 480 Progressive 126.000 240.000 108.108
480p2x59 1440 x 480 Progressive 31.469 59.940 54.000
480p2x60 1440 x 480 Progressive 31.500 60.000 54.054
480p2xL1 1440 x 480 Progressive 31.469 59.940 54.000
480p2xL2 1440 x 480 Progressive 31.500 60.000 54.054
480p2xS1 1440 x 480 Progressive 31.469 59.940 54.000
480p2xS2 1440 x 480 Progressive 31.500 60.000 54.054
480p4x59 2880 x 480 Progressive 31.469 59.940 108.000
480p4x60 2880 x 480 Progressive 31.500 60.000 108.108
480p4xL1 2880 x 480 Progressive 31.469 59.940 108.000
480p4xL2 2880 x 480 Progressive 31.500 60.000 108.108
480p4xS1 2880 x 480 Progressive 31.469 59.940 108.000
480p4xS2 2880 x 480 Progressive 31.500 60.000 108.108
480p59 720 x 480 Progressive 31.469 59.940 27.000
480p59LH 720 x 480 Progressive 31.469 59.940 27.000
480p59SH 720 x 480 Progressive 31.469 59.940 27.000
480p60 720 x 480 Progressive 31.500 60.000 27.027
480p60LH 720 x 480 Progressive 31.500 60.000 27.027
480p60SH 720 x 480 Progressive 31.500 60.000 27.027
480pWH 960 x 480 Progressive 31.469 59.940 36.000
487i 720 x 487 Interlace 15.734 59.939 13.500
576i 720 x 576 Interlace 15.625 50.000 13.500
576i# 720 x 576 Interlace 15.625 50.000 14.750
576i#KA 720 x 576 Interlace 15.625 50.000 14.750
576i2x_1 720 x 576 Interlace 62.500 200.000 54.000
576i2x25 720 x 576 Interlace 16.625 50.000 13.500
576i2x50 720 x 576 Interlace 31.250 100.000 27.000
576i2xL1 720 x 576 Interlace 31.250 100.000 27.000
576i2xL2 720 x 576 Interlace 62.500 200.000 54.000
576i2xLH 720 x 576 Interlace 16.625 50.000 13.500
576i2xS1 720 x 576 Interlace 31.250 100.000 27.000
576i2xS2 720 x 576 Interlace 62.500 200.000 54.000
576i2xSH 720 x 576 Interlace 15.625 50.000 13.500
576i4x25 2880 x 576 Interlace 15.625 50.000 54.000
Format
Active
(HxV) Scan
Horizontal
Rate (kHz)
Vertical
Rate (Hz)
Pixel
Rate (MHz)
