882 Video Test Instrument User Guide (Rev A.35) 689
576i4xLH 2880 x 576 Interlace 15.625 50.000 54.000
576i4xSH 2880 x 576 Interlace 15.625 50.000 54.000
576i50 720 x 576 Interlace 31.250 100.000 27.000
576i50_H 960 x 576 Interlace 31.250 100.000 37.125
576i50_L 960 x 576 Interlace 31.250 100.000 37.125
576i50WH 960 x 576 Interlace 31.250 100.000 36.000
576i50WL 960 x 576 Interlace 31.250 100.000 36.000
576iLH 720 x 576 Interlace 15.625 50.000 13.500
576iSH 720 x 576 Interlace 15.625 50.000 13.500
576iWH 960 x 576 Interlace 15.625 50.000 18.000
576p# 768 x 576 Progressive 31.250 50.000 29.500
576p100 720 x 576 Progressive 62.500 100.000 54.000
576p100L 720 x 576 Progressive 62.500 100.000 54.000
576p100S 720 x 576 Progressive 62.500 100.000 54.000
576p200 720 x 576 Progressive 125.000 200.000 108.000
576p200L 720 x 576 Progressive 125.000 200.000 108.000
576p200S 720 x 576 Progressive 125.000 200.000 108.000
576p2x50 1440 x 576 Progressive 31.250 50.000 54.000
576p2xLH 1440 x 576 Progressive 31.250 50.000 54.000
576p2xSH 1440 x 576 Progressive 31.250 50.000 54.000
576p4x50 2880 x 576 Progressive 31.250 50.000 108.000
576p4xLH 2880 x 576 Progressive 31.250 50.000 108.000
576p4xSH 2880 x 576 Progressive 31.250 50.000 108.000
576p50 720 x 576 Progressive 31.250 50.000 27.000
576p50LH 720 x 576 Progressive 31.250 50.000 27.000
576p50SH 720 x 576 Progressive 31.250 50.000 27.000
576pWH 960 x 576 Progressive 31.250 50.000 36.000
576pWH_ 960 x 576 Progressive 31.250 50.000 37.125
576pWL 960 x 576 Progressive 31.250 50.000 36.000
576pWL_ 960 x 576 Progressive 31.250 50.000 37.125
Betacam 768 x 480 Interlace 15.734 59.940 14.318
NTSC#KA 640 x 480 Interface 15.734 59.940 12.273
NTSC# 640 x 480 Interface 15.734 59.940 12.273
NTSC 710x 480 Interface 15.734 59.940 13.500
NTSC-LH 720 x 480 Interface 15.734 59.940 13.500
NTSC-SH 720 x 480 Interface 15.734 59.940 13.500
NTSC-J 710 x 480 Interface 15.734 59.940 13.500
NTSC-JLH 720 x 480 Interface 15.734 59.940 13.500
NTSC-JSH 720 x 480 Interface 15.734 59.940 13.500
NTSC44 720 x 480 Interface 15.734 59.940 13.500
PAL-60 710 x 480 Interface 15.734 59.940 13.500
PAL-M 710 x 480 Interface 15.734 59.940 13.500
PAL-N 702 x 574 Interface 15.625 50.000 13.500
PAL#KA 768 x 574 Interface 15.625 50.000 14.750
PAL# 768 x 574 Interface 15.625 50.000 14.750
PAL 702 x 574 Interface 15.625 50.000 13.500
PAL-NC 720 x 574 Interface 15.625 50.000 13.500
Format
Active
(HxV) Scan
Horizontal
Rate (kHz)
Vertical
Rate (Hz)
Pixel
Rate (MHz)
