882 Video Test Instrument User Guide (Rev A.35) 697
Medical Formats
240p4xL4 2880 x 240 Progressive 15.750 59.886 54.054
240p4xS1 2880 x 240 Progressive 15.734 60.055 54.000
240p4xS2 2880 x 240 Progressive 15.750 60.115 54.054
240p4xS3 2880 x 240 Progressive 15.734 59.826 54.000
240p4xS4 2880 x 240 Progressive 15.750 59.886 54.054
288p2x_1 720 x 288 Progressive 15.625 50.080 13.500
288p2x_2 720 x 288 Progressive 15.625 49.920 13.500
288p2x_3 720 x 288 Progressive 15.625 49.761 13.500
288p2xL1 720 x 288 Progressive 15.625 50.080 13.500
288p2xL2 720 x 288 Progressive 15.625 49.920 13.500
288p2xL3 720 x 288 Progressive 15.625 49.761 13.500
288p2xS1 720 x 288 Progressive 15.625 50.080 13.500
288p2xS2 720 x 288 Progressive 15.625 49.920 13.500
288p2xS3 720 x 288 Progressive 15.625 49.761 13.500
288p4x_1 2880 x 288 Progressive 15.625 50.080 54.000
288p4x_2 2880 x 288 Progressive 15.625 49.920 54.000
288p4x_3 2880 x 288 Progressive 15.625 49.761 54.000
288p4xL1 2880 x 288 Progressive 15.625 50.080 54.000
288p4xL2 2880 x 288 Progressive 15.625 49.920 54.000
288p4xL3 2880 x 288 Progressive 15.625 49.761 54.000
288p4xS1 2880 x 288 Progressive 15.625 50.080 54.000
288p4xS2 2880 x 288 Progressive 15.625 49.920 54.000
288p4xS3 2880 x 288 Progressive 15.625 49.761 54.000
Format
Active
(HxV) Scan
Horizontal
Rate (kHz)
Vertical
Rate (Hz)
Pixel
Rate (MHz)
Format
Active
(HxV) Scan
Horizontal
Rate (kHz)
Vertical
Rate (Hz)
Pixel
Rate (MHz)
DatRay5 2048 x 2560 Progressive 186.010 70.996 499.99488
DatRay6 2456 x 2560 Progressive 186.010 70.996 607.880704
DatRay7 2864 x 2560 Progressive 186.010 70.996 700.885696
DatRay8 3280 x 2560 Progressive 186.010 70.996 800.587008
DOM1266O 1200 x 1600 Progressive 109.752 66.316 186.140
DOM1570O 1536 x 2048 Progressive 147.183 70.423 357.950016
DOM1762O 1728 x 2304 Progressive 146.437 61.866 360.820
DOM1763O 1728 x 2304 Progressive 148.364 62.893 360.820
DOM1769O 1728 x 2304 Progressive 163.415 69.039 360.820
DOM1770X 1712 x 2100 Progressive 149.346 69.528 360.820
DOM2060_ 2048 x 2048 Progressive 126.847 60.003 357.200
DOM2060Q 2048 x 2044 Progressive 127.769 60.382 360.820
DOM2065X 2048 x 2560 Progressive 169.891 65.092 500.159968
DOM2071X 2048 x 2560 Progressive 186.079 71.022 500.180032
DOM2076A 2048 x 1536 Progressive 118.691 75.599 360.820
DOM2076X 2048 x 2560 Progressive 199.449 76.009 542.500032
