698 Appendix D Format Reference
Military Formats
TTL Formats
DOM2365 2304 x 1728 Progressive 116.244 64.904 360.819968
DOM2569G 2560 x 2048 Progressive 144.722 69.014 500.160
DOM2571G 2560 x 2048 Progressive 150.289 71.703 500.160032
MATROX 1280 x 1024 Progressive 77.000 72.368 133.056
Md2 1200 x 1600 Progressive 124.430 75.504 214.019984
Md2SBX 1600 x 1200 Progressive 91.118 73.011 200.460
Md4SBX 1728 x 2304 Progressive 163.415 69.039 360.820
Md5SBV 2048 x 2560 Progressive 199.449 76.009 542.500032
Md5SBX 2048 x 2560 Progressive 186.012 70.997 500.000
Format
Active
(HxV) Scan
Horizontal
Rate (kHz)
Vertical
Rate (Hz)
Pixel
Rate (MHz)
Format
Active
(HxV) Scan
Horizontal
Rate (kHz)
Vertical
Rate (Hz)
Pixel
Rate (MHz)
HOBO 752 x 482 Interlace 15.734 59.940 14.444056
LMC_1 640 x 480 Interlace 15.734 59.940 12.272727
LMC_2 640 x 480 Interlace 15.734 59.940 12.272727
LMC_3 640 x 480 Interlace 15.734 59.940 12.272727
LMC_4 640 x 480 Interlace 15.734 59.940 12.272727
MAVERIK 740 x 476 Interlace 15.734 59.940 14.318182
STANAGA 1244 x 842 Interlace 26.250 60.000 40.005
STANAGB 1560 x 574 Interlace 15.625 50.000 30.000
STANAGC 1262 x 484 Interlace 15.750 60.000 24.003
XGA2 720 x 400 Progressive 39.444 87.849 35.4996
Format
Active
(HxV) Scan
Horizontal
Rate (kHz)
Vertical
Rate (Hz)
Pixel
Rate (MHz)
AT&T_EVC 640 x 350 Progressive 25.862 59.866 24.000
AT&T_IVC 640 x 400 Progressive 25.862 59.866 24.000
AT&T_SVC 640 x 400 Progressive 25.862 59.866 24.000
CGA_m14 640 x 200 Progressive 15.700 59.924 14.3184
EGA_m2 640 x 350 Progressive 21.851 59.702 16.257144
HGC_text 720 x 350 Progressive 18.141 49.030 16.000362
HGCgraph 720 x 348 Progressive 18.519 50.051 16.000416
IBM_3164 640 x 400 Progressive 27.648 64.749 22.1184
IBM_3179 640 x 400 Progressive 25.560 60.000 20.488
MDA_m7 720 x 350 Progressive 18.432 49.816 16.257144
