Quantum Data 881 - Page 1137

882 Video Test Instrument User Guide (Rev A.35) 699
Misc. Formats
Test Formats
Format
Active
(HxV) Scan
Horizontal
Rate (kHz)
Vertical
Rate (Hz)
Pixel
Rate (MHz)
CEA0659 640 x 480 Progressive 31.469 59.941 25.1752
EIA0629 640 x 480 Interlace 15.734 59.940 12.272727
EIA0629K 512 x 384 Interlace 15.734 59.940 12.272727
EIA0729 752 x 484 Interlace 15.734 59.940 14.318182
EIA0729X 752 x 484 Interlace 15.734 59.940 14.318182
ICS1160 1184 x 884 Progressive 55.200 60.000 83.0208
ICS1176 1184 x 884 Progressive 71.712 76.047 105.560504
ICS1660 1664 x 1248 Progressive 77.940 60.000 164.609296
ICS1676 1664 x 1248 Progressive 100.726 76.020 211.121888
ITU0725 768 x 574 Interlace 15.625 50.000 14.750
ITU0725K 640 x 480 Interlace 15.625 50.000 14.750
ITU0925X 920 x 574 Interlace 15.625 50.000 17.750
LD6Du60 1024 x 768 Progressive 48.364 60.005 65.001216
LD8Du75 1024 x 768 Progressive 60.023 75.029 78.750
NEC0656D 640 x 400 Progressive 24.823 56.416 21.050
NEC1140B 1120 x 750 Interlace 32.857 80.042 47.840004
Format
Active
(HxV) Scan
Horizontal
Rate (kHz)
Vertical
Rate (Hz)
Pixel
Rate (MHz)
RAMP160 4096 x 480 Progressive 31.469 59.941 161.121280
TEST81 1024 x 768 Progressive 61.738 77.172 81.000
TEST150 2048 x 1024 Progressive 50.403 46.887 150.000
TEST165 1600 x 1200 Progressive 76.389 61.111 165.000
TEST250 2048 x 2048 Interlace 79.719 71.722 250.000016
TEST330 2048 x 1536 Progressive 94.178 59.269 330.000
tst300i 2048 x 1536 Interlace 94.178 118.538 299.86304
tst300p 2048 x 1536 Progressive 94.178 59.269 299.86304
tst360i 2816 x 1024 Interlace 97.000 91.037 360.064
tst360p 2816 x 1024 Progressive 97.000 91.080 360.064
tst400i 2816 x 1024 Interlace 97.000 91.037 399.640
tst400p 2816 x 1024 Progressive 97.000 91.080 399.640
