174 Chapter 5 Working with Formats
ACS Type Sets the analog composite sync type of the format. The parameter is ASCT.
The following are the selections:
• None
• American ORed
• American Single Serrated
• American Double Serrated (ref SMPTE 170M NTSC)
• Australian AS 493.1-200X CS Serrated
• European ORed
• European Double Serrated (ref ITU-R BT.470-6 PAL)
• SMPTE 296M-EIA/CEA
• HDTV Double Serrated (ref SMPTE 296M)
• SMPTE 295M-EIA/CA
• HDTV Double Serrated (ref SMPTE 295M)
• SMPTE 274M-EIA/CA
• HDTV Double Serrated (ref SMPTE 240M, 260M, 274M)
DCS Type Sets the digital composite sync type of the format. The parameter is DSCT.
The following are the selections:
• None
• American ORed
• American Single Serrated
• American Double Serrated (ref SMPTE 170M NTSC)
• Australian AS 493.1-200X CS Serrated
• European ORed
• European Double Serrated (ref ITU-R BT.470-6 PAL)
Field / Entity Description / Function
