882 Video Test Instrument User Guide (Rev A.35) 179
AVI Video
Identification Code
Entry field The digital video code corresponding to the
EIA/CEA-861 standard. Parameter: DVIC.
Number of Links Radio button
1 Sets the number of links to 1 by the DVI output.
2 Sets the number of links to 2 for the DVI output
Parameter: NLNK
Protocol Type Pull-down select Specifies which digital output is active through the HDMI
interface. Allowable values are:
• DVI - Enables DVI mode out the DVI output or the
HDMI output.
• HDMI - Enables HDMI mode out the HDMI output.
Parameter: XVSI
Sampling Mode Pull-down select Specifies the digital sampling mode. Allowable values
are:
• Default - RGB 4:4:4.
• 4:2:2 - Color difference components are sampled at
half the pixel rate. Luminance is sampled at the full
pixel rate. Requires that the YCbCr color mode be
selected with the DVST command.
• 4:4:4 - Color difference components and luminance
component is sampled at the full pixel rate. Requires
that the YCbCr color mode be selected with the DVST
command.
Parameter: DVSM
Bits per Color
Component
Pull-down select Specifies the number of bits per component. Allowable
values are:
• Default - Use the default setting in the generator.
• 6 - Six bits per component.
• 8 - Eight bits per component.
• 10 - Ten bits per component.
• 12 - Twelve bits per component.
Parameter: NBPC
Video Swing 1 Entry field Sets the digital video voltage swing for the HDMI output
1. The range of values is: 0.150 to 1.560
Parameter is: DVSS
Video Swing 2 Entry field Sets the digital video voltage swing for the HDMI output
2. The range of values is: 0.150 to 1.560
Parameter is: DVSS
Entity / Field Type Description / Function
