882 Video Test Instrument User Guide (Rev A.35) 289
The following table describes the X3DM Command Parameters.
Examples:
X3DM 1 0 // enables 3D, sends Frame Packing
X3DM 1 8 3 // enables 3D, sends side by side using Even/Left
picture, Even/Right picture horizontal subsampling
X3DM 0 // disables 3D
Parameter No. Descriptions Value Permitted
1 Enable or disable 3D 0 - Disable
1 - Enable
2 3D Method 0 - Frame Packing
2 - Line Alternative
3 - Side by Side (Full)
4 - L + Depth
6 - Top and Bottom
8 - Side by Side (Half)
3 Applies to Side by Side
(half) only
Horizontal Sub-Sampling:
0 - Odd/Left picture, Odd/Right picture
1 - Odd/Left picture, Even/Right picture
2 - Odd/Left picture, Odd/Right picture
3 - Odd/Left picture, Even/Right picture
Quincunx Matrix:
4 - Odd/Left picture, Odd/Right picture
5 - Odd/Left picture, Even/Right picture
6 - Odd/Left picture, Odd/Right picture
7 - Odd/Left picture, Even/Right picture
