310 Chapter 9 Testing HDMI Sink Devices
Note: The contents of the appropriate InfoFrame output appears on the HDMI display.
Alternatively, to select an image version using the command line interface, enter the
following commands:
ISUB 1 // Enables sub images
IVER 1 // Specifies the first image version
IMGU // Activates the image version
5. Select additional InfoFrame subimages (as desired) to verify proper InfoFrame
handling.
6. When testing is complete, disable image versions by pressing the Options key and
choosing More until a - appears next to it.
Alternatively, to disable image versions using the command line interface, enter the
following command:
ISUB 0 // Disables sub images
To generate a report for the PacketTx image:
1. Press the Tools key. The Tools menu appears on the 882’s display as shown below.
2. Choose the Reports item by pressing the adjacent soft key. The Reports menu
appears on the 882’s display as shown below.
3. Choose the Packets item by pressing the adjacent soft key. The Packet menu appears
on the 882’s display as shown below.
Note: Be sure that you have transferred any existing PacketTx reports to your PC
otherwise generating a new report will overwrite the existing report.
System
Sequence
Probe
AFC
Analyzer
Reports
ImgShift
EDID
Packets
