14 Chapter 11 Testing EDID for HDMI
720x576p/50 4:3 Indicates whether the sink supports the 576p50 format
with a 4:3 aspect ratio. The values are + for yes and - for
no.
720x576p/50 16:9 Indicates whether the sink supports the 576p50 format
with a 16:9 aspect ratio. The values are + for yes and -
for no.
1280x720p/50 16:9 Indicates whether the sink under test supports the
720p50 format. The values are + for yes and - for no.
1920x1080i/50 16:9 Indicates whether the sink under test supports the
1080i50 format. The values are + for yes and - for no.
1440x576i/50 4:3 Indicates whether the sink under test supports the
576i2x50 format with double clocking at 4:3 aspect ratio.
The values are + for yes and - for no.
1440x576i/50 16:9 Indicates whether the sink under test supports the
576i2x50 format with double clocking at 16:9 aspect
ratio. The values are + for yes and - for no.
1440x480i/50 4:3 Indicates whether the sink under test supports the
480i2x50 format with double clocking at 4:3 aspect ratio.
The values are + for yes and - for no.
1440x480i/50 16:9 Indicates whether the sink under test supports the
480i2x50 format with double clocking at 16:9 aspect
ratio. The values are + for yes and - for no.
720p/60 On Other Indicates whether the sink under test supports the ana-
log component video input for 720p60. The values are +
for yes and - for no.
1080i/60 On Other Indicates whether the sink under test supports the ana-
log component video input for 1080i60. The values are
+ for yes and - for no.
480p/60 On Other Indicates whether the sink under test supports the ana-
log component video input for 480p60. The values are +
for yes and - for no.
720p/50 On Other Indicates whether the sink under test supports the ana-
log component video input for 720p50. The values are +
for yes and - for no.
1080i/50 On Other Indicates whether the sink under test supports the ana-
log component video input for 1080i50. The values are
+ for yes and - for no.
576p/50 On Other Indicates whether the sink under test supports the ana-
log component video input for 576p50. The values are +
for yes and - for no.
Supports AI Indicates whether the sink under test supports audio
information. The values are + for yes and - for no.
HDMI 1.4 Testing Does the sink support HDMI 1.4 features. The values
are + for yes and - for no.
Parameter Explanation
