882 Video Test Instrument User Guide (Rev A.35) 15
3D Does the sink support 3D formats. The values are + for
yes and - for no.
3D Additional Does the sink support 3D additional formats in addition
to the mandatory 3D formats. The values are + for yes
and - for no.
4K x 2K Does the sink support 4K x 2K formats. The values are
+ for yes and - for no.
Basic Audio Indicates whether the sink supports basic audio. The
values are + for yes and - for no.
Connector Type A Indicates whether the sink under test input connector is
a Type A connector.
Write Protected Indicates whether the EDID of the sink under test is
write protected.
HDMI 1.3B CTS Indicates whether to test sink against HDMI Compliance
Test Specification (CTS) 1.3b or 1.2a. The values are +
for 1.3b or - for 1.2a.
Deep Color Indicates whether the sink under test supports deep
color. The values are + for yes and - for no.
DC 30 Bit Indicates whether the sink under test supports deep
color at 30 bits per pixel. The values are + for yes and -
for no.
DC 36 Bit Indicates whether the sink under test supports deep
color at 36 bits per pixel. The values are + for yes and -
for no.
DC 48 Bit Indicates whether the sink under test supports deep
color at 48 bits per pixel. The values are + for yes and -
for no.
DC YCbCr 4:4:4 Indicates whether the sink under test supports deep
color in YCbCr 4:4:4. The values are + for yes and - for
no.
xvYCC Indicates whether the sink under test supports
xvYCC601 or xvYCC709. The values are + for yes and
- for no.
Exceeds 165MHz Indicates whether the sink under test supports any
video format/color mode with a TMDS clock frequency
above 165MHz. The values are + for yes and - for no.
1920x1080p/60 16:9 Indicates whether the sink under test supports the
1080p60 format at 16:9 aspect ratio. The values are +
for yes and - for no.
1920x1080p/50 16:9 Indicates whether the sink under test supports the
1080p50 format at 16:9 aspect ratio. The values are +
for yes and - for no.
Parameter Explanation
