882 Video Test Instrument User Guide (Rev A.35) 17
Note: You may have to select a valid HDMI format at this point.
a. Press the Interface key. A listing of signal interfaces appears on the 882’s display
as shown below.
b. Choose the HDMI-H item by pressing the adjacent soft key. The interface is
activated and the port outputs the currently selected image and format.
c. Alternatively, to activate the interface through the command line interface, enter the
following commands:
XVSI 4 // Selects the HDMI-H interface
ALLU // Applies the interface setting to the 882
4. Press the Sink key, and then press the Options key. The following menu appears on
the 882’s display:
Cho
5. Choose the CDF item by pressing the adjacent soft key. The CDF parameters appear
on the 882’s display as shown below.
Cho.
6. Set characteristics of the display under test using CDF parameters. Scroll through the
list by pressing the + key.
Refer to “Defining the capabilities of the display device under test” on page 12 for
definitions for each parameter in the CDF.
Note: If you are running the EDID compliance test through the Compliance Controller,
you do not need to configure the CDF through the front panel.
VGA
HDMI-D
CVBS
S-VIDEO
SDI
*
HDMI-H
VGA
HDMI-D
CVBS
S-VIDEO
SDI
*HDMI-H
-EDID Formats CDF
+HP Bypass
-Emulate
0:HDMI Output Count
1:HDMI Input Port
-CEC Root Device
>Primary AR: 4:3
