18 Chapter 11 Testing EDID for HDMI
Running the EDID compliance test through the front panel
Use the following procedure to run the EDID compliance test through the front panel. You
can run the EDID compliance test through the front panel either by using the EDIDHDMI
image or the EDID compliance report. Refer to “Running the HDMI EDID Compliance test
report” on page 24 for instructions on running the EDID compliance test through the
compliance report feature.
To perform HDMI sink EDID compliance testing using the EDID HDMI image:
1. Set up 882 for HDMI sink testing for EDID compliance. See “Setting up 882 for HDMI
sink device EDID compliance testing” on page 16 on for details.
2. Press the Content key and choose the EdidHDMI image for testing displays
connected to HDMI output 1 (usee EDIDHDM2 image for HDMI output 2) by pressing
the adjacent soft key.
Alternatively, to select the image through the command line interface, enter the
following command:
IMGL EdidHDMI
IMGU
3. Enable image versions for the EdidHDMI/EdidHDM2 image as follows:
a. Press the Options key. The following menu appears on the 882’s display:
b. Choose the More item by pressing the adjacent soft key until a + and Rendition
appears next to the item.
Alternatively, to enable and view image versions using the command line interface,
enter the following commands:
ISUB 1 // Enables sub images
IVER 1 // Specifies the first image version
IMGU // Activates the image version
4. Press the + key to advance through the image versions and view results for tests 8-1,
8-2, 8-3, 8-17, 8-18, and 8-19. Test descriptions and sample screens are provided
below.
-More
Red+
-NoGamma Green+
-Noise Blue+
+More Rendition: 000
Red+
-NoGamma Green+
-Noise Blue+
To Next Page
