882 Video Test Instrument User Guide (Rev A.35) 35
2. Activate the HDMI-H interface on the output port:
a. Press the Interface key to access the list of interfaces. A listing of signal interfaces
appears on the 882’s display as shown below.
b. Choose the HDMI-H item by pressing the adjacent soft key.
The interface is activated and the port outputs the currently selected image and format.
Alternatively, to select the interface through the command line, enter the following
commands:
XVSI 4 // Selects the HDMI-H interface
ALLU // Applies the interface setting to the 882
3. Press the Source key and choose a valid HDMI format (for example, DMT0660) by
pressing the adjacent soft key.
Alternatively, to select the format through the command line interface, enter the
following command:
FMTL DMT0660
FMTU
VGA
HDMI-D
CVBS
S-VIDEO
SDI
*
HDMI-H
VGA
HDMI-D
CVBS
S-VIDEO
SDI
*HDMI-H
