882 Video Test Instrument User Guide (Rev A.35) 127
13. Press the Tools key get back to the Reports menu.
The 882 LCD will display the reports menu as shown below.
14. Select HDCP to access the HDCP compliance test menu.
The following is displayed on the 882’s LCD.
15. Select !CompRpt to initiate the HDCP compliance test. Initiate each test individually.
The message “HDCP Compliance Test” is shown and then all the tests are shown in
sequence.
Alternatively, to run a specific test through the command line:
CPTX:CPTR 1 // Selects specific test (e.g. 1A_01) see table below
CPTX:CPTU // Initiates the execution of the test.
You can query the complete list of tests to choose from:
CPTX:GCTN? // Queries the list of tests supported.
You can query the currently selected test to run with:
CPTX:CPTR? // Queries the selected test to run (see table
below).
Refer to “To view the HDCP compliance report:” on page 605 for procedures on how to
view the generated report.
The following table describes tests run with the CPTX:CPTR command for the 882EA.
CPTX:CPTR
I
ndex Test Description
1 1A_01 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
Regular Procedure: With HDMI Capable
Receiver
2 1A_02 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
Regular Procedure: HPD After Writing Aksv
EDID Packets
Misc HDCP
!CompRpt EditPCP
