128 Chapter 13 Testing HDCP on HDMI
16. Monitor the 882EA LCD for a set of prompts during the 1A-01, 1A-09, and 1B-01 tests.
Note: You will not be prompted as shown below when running the test with the 882CA.
a. When prompted with the screen shown below, examine the video on the display
connected to 882EA output 1. Press the appropriate button adjacent to the
indication (Yes! or No!) to continue.
3 1A_03 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
Regular Procedure: HPD After Starting Third
Part of Authentication
4 1A_04 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
Irregular Procedure: (First Part of
Authentication) HDPC Port Access
5 1A_05 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
Irregular Procedure: (First Part of
Authentication) Verify Bksv
6 1A_06 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
Irregular Procedure: (First Part of
Authentication) Verify R0'
7 1A_07 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
Irregular Procedure: (Third Part of
Authentication) Verify Ri' (Ri’ invalid)
8 1A_07a (Transmitter Down-
stream w/Receiver) w/HDMI
Capable Receiver
Irregular Procedure: (Third Part of
Authentication) Verify Ri' (Ri’ not returned)
9 1A_08 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
Irregular Procedure: SRM. Requires SRM disc.
10 1A_09 (Transmitter Downstream
w/Receiver) w/DVI Receiver
Regular Procedure: With DVI Receiver
11 1B_01 (Transmitter Downstream
w/Repeater)
Regular Procedure: With Repeater
12 1B_02 (Transmitter Downstream
w/Repeater)
Regular Procedure: HDCP_HPD After Read-
ing R0'
13 1B_03 (Transmitter Downstream
w/Repeater)
Irregular Procedure: (Second Part of
Authentication) Timeout of KSV List READY
14 1B_04 (Transmitter Downstream
w/Repeater)
Irregular Procedure: (Second Part of
Authentication) Verify V'
15 1B_05 (Transmitter Downstream
w/Repeater)
Irregular Procedure: (Second Part of
Authentication) MAX_DEVS_EXCEEDED
16 1B_06 (Transmitter Downstream
w/Repeater)
Irregular Procedure: (Second Part of
Authentication) MAX_CASCADE_EXCEEDED
CPTX:CPTR
I
ndex Test Description
