136 Chapter 13 Testing HDCP on HDMI
2. Activate the HDMI-H interface on the output port as follows:
a. Press the Interface key. A listing of signal interfaces appears on the 882’s display
as shown below.
b. Choose the HDMI-H item by pressing the adjacent soft key. The interface is
activated and the display is shown below.
Alternatively, to activate the interface through the command line interface, enter the
following commands:
XVSI 4 // Activates the HDMI-H interface
ALLU // Applies the interface setting to the 882
3. Press the Interface key repeatedly until the following menu appears:
4. Choose the HDMI IN 1 by pressing the adjacent soft key.
5. Verify that the repeater is sending in video using the Timing measurement function of
the analzyer. Refer to “Measuring timing of video signal” on page 260 for information
on running the timing test.
Verify that the source is outputting one of the following formats: 1) 640x480p at
59.94/60Hz; 2) 720x480p at 59.94/60Hz; 3) 720x576p at 50Hz.
Verify that the source is outputing the RGB color space:
If the 882 cannot detect the incoming video, enter the following command to turn on the
EST:
QD:PROD:EST // Turns on the EST
6. Press the Tools key and choose the Reports item by pressing the adjacent soft key.
The following is displayed on the 882’s LCD.
VGA
HDMI-D
CVBS
S-VIDEO
SDI
*
HDMI-H
VGA
HDMI-D
CVBS
S-VIDEO
SDI
*HDMI-H
HDMI IN 1
HDMI IN 2
*
EDID Packets
Misc HDCP
To Next Page
