882 Video Test Instrument User Guide (Rev A.35) 137
7. Select HDCP to access the HDCP compliance test menu.
The following is displayed on the 882’s LCD.
8. Select EditPCP to define the capabilities of the HDCP device under.
The following is displayed on the 882’s LCD.
The following table describes the test parameters and their settings (gray = N/A).
Parameter Explanation
CTS Version Specifies whether you wish to test to the HDCP CTS 1.1
or HDCP CTS 1.2. Please note you will not be able to
select CTS 1.2 if the HDCP CTS 1.2 option is not
enabled on the 882EA.
DUT type Specifies the type of device under test. This can be one
of Sink, Source, Repeater3AB, or Repeater3C. For this
test, select Repeater3AB.
Test Number Specifies which test to run. Or enables you to select all
tests. Please note that Quantum Data highly recom-
mends running the tests individually.
Repeater Max KSV Specifies the maximum number of KSVs the repeater
DUT can support. The valid values are 2 through 127.
Repeater Authentication Count Specifies the number of times a repeater DUT attempts
authentication before transitioning into the authentica-
tion state. The valid values are 1 or greater.
Repeater CP&EDID HPD
(Not used in HDCP 1.1)
(Not used for 3AB tests.
Only applies to 3C tests)
Indicates whether the repeater supports the handling of
the Content Protection and EDID hot plug detect sig-
nal.The values are + for yes and - for no.
Repeater Short Read Ri
(Not used for 3AB tests.
Only applies to 3C tests)
Indicates whether the repeater DUT will respond to
short reads of the Ri register. The values are + for yes
and - for no.
Repeater 1.1 Features Supported
(Not used for 3AB tests.
Only applies to 3C tests)
Indicates whether repeater DUT supports
Advanced_Cipher mode and Enhanced Link Verifica-
tion. The values are + for yes and - for no.
Repeater Audio Support
(Not used for 3AB tests.
Only applies to 3C tests)
Indicates whether the repeater DUT supports audio out-
put. The values are + for yes and - for no.
!CompRpt EditPCP
1.2 :CTS Ver.
Rptr 3AB :DUT Type
+All :Test Num-
+2 :Rptr Max KSV -
To Next Page
