146 Chapter 13 Testing HDCP on HDMI
The following table describes the tests performed with the 882EA.
CPTX:CPTR
I
ndex Test Description
31 3C_I_01 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver)
Regular Procedure: Transmitter – DUT –
Receiver
32 3C_I_02 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver)
Regular Procedure: HDCP_HPD Pulse Output
Caused By User Operation
33 3C_I_03 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver)
Irregular Procedure: (First Part of
Authentication) New Authentication
34 3C_I_04 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver)
Irregular Procedure: (Second Part of
Authentication) New Authentication
35 3C_I_05 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver)
Irregular Procedure: (Third Part of
Authentication) New Authentication
36 3C_I_06 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver)
Irregular Procedure: (Second Part of
Authentication) Verify Bksv
37 3C_I_07 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver)
Irregular Procedure: (Second Part of
Authentication) Verify R0'
38 3C_II_01 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and
Repeater)
Regular Procedure: Transmitter – DUT –
Repeater+Receiver
39 3C_II_02 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and
Repeater)
Regular Procedure: HDCP_HPD After Writing
Aksv
40 3C_II_03 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and
Repeater)
Regular Procedure: HDCP_HPD After Read-
ing R0'
41 3C_II_04 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and
Repeater)
Regular Procedure: HDCP_HPD After Starting
Third Part of Authentication
