882 Video Test Instrument User Guide (Rev A.35) 145
12. Press the Tools key get back to the Reports menu.
The 882 LCD will display the reports menu as shown below.
13. Select HDCP to access the HDCP compliance test menu.
The following is displayed on the 882’s LCD.
14. Select !CompRpt to initiate the HDCP compliance test. Initiate each test individually.
The message “HDCP Compliance Test” is shown and then all the tests are shown in
sequence.
Refer to “To view the HDCP compliance report:” on page 605 for procedures on how to
view the generated report.
Alternatively, to run a specific test you can use the command line as shown below:
CPTX:CPTR 31 // Selects specific test (e.g. 3C-I-01) see
table below
CPTX:CPTU // Initiates the execution of the test
You can query the complete list of tests to choose from:
CPTX:GCTN? // Queries the list of tests supported
You can query the currently selected test to run with:
CPTX:CPTR? // Queries the selected test to run (see table)
EDID Packets
Misc HDCP
!CompRpt EditPCP
To Next Page
