Viewing VPN Tunnels
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 240
Viewing VPN Tunnels
In the VPN Tunnels page, you can see current VPN tunnels opened between this gateway and remote
sites. Some sites are configured so tunnels are established only when necessary and some are configured
with permanent tunnels. When the appliance is managed by Cloud Services, this table also shows the
tunnels for the gateways in the community.
The table below shows the details of each tunnel configured:
Field Description
From The external interface the tunnel uses.
Site Name The VPN site name.
Peer Address Host name or IP address of the tunnel's destination gateway.
Community
Name
If the gateways are part of a community configured by Cloud Services, the
community name with which the tunnel is associated.
Status Indicates if a tunnel is up or is pending traffic to become active.
Phase 2
Methods
Encryption and authentication methods used for the tunnel.
My encryption
domain
Indicates the tunnel's selectors (subnets/hosts) allowed from the source
gateway.
Peer's
encryption
domain
Indicates the tunnel's selectors (subnets/hosts) allowed from the
destination gateway.
Connections
per instance
The number of connections associated with the tunnel per instance. This
lets you know if a tunnel is over-utilized.
To filter the list:
In the Type to filter box, enter the filter criteria.
To refresh the list:
Click Refresh to refresh manually this page with updated tunnel information.
Note - This page is available from the VPN and Logs & Monitoring tabs.
