Configuring the Local Network
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 80
For example, to monitor the traffic after the router, enter the IP address of the Default Gateway and
the 255.255.255.255 subnet.
9. Click Apply.
The Internal network you defined (with Monitor Mode in the name) shows in the list of interfaces.
Note - You can configure multiple local networks to be in monitor mode at the same time.
After you configure monitor mode:
1. Go to Device > Advanced Settings.
2. Turn off Anti-Spoofing.
To configure monitor mode in Gaia Clish:
1. To define a port for Monitor Mode:
set interface <Port Name> monitor-mode
2. To configure Monitor Mode Automatic Learning, disable user-defined networks:
set monitor-mode-configuration use-defined-networks false
3. To configure Monitor Mode with user-defined networks:
add monitor-mode-network ipv4-address <IP Address> subnet-mask <Mask>
set monitor-mode-configuration use-defined-networks true
4. To see user-defined Internal networks:
show monitor-mode-network
5. To disable Anti-Spoofing:
set antispoofing advanced-settings global-activation false
If you do not see the Monitor Mode option:
1. Run this command in Gaia Clish:
set monitor-mode-configuration allow-monitor-mode true
2. Select an interface in WebUI and click Edit.
Monitor Mode is now added to the options list.
For more information on monitor mode, see sk112572.
Physical Interfaces
To edit a physical interface:
Configure the fields in the tabs. Note that for the DMZ there is an additional tab Access Policy:
The 'Configuration' tab
Assigned to - Select the required option:
