Radwin 5000 Installation Guide

RADWIN 5000 Installaon Guide
August 2023
110
Cat. No.
Type
Gain (dBi)
Dir
BW
Tx Power per
chain (dBm)
Min. Safe
Distance (cm)
RW‐9732‐4958
Dish DP
30.0
4°
25
225
The RADWIN SU PRO/AIR EMB bears the following FCC/IC IDs on the label. Refer to Table 14 to Table 18
below:
FCC ID: Q3K‐5XACULC‐X IC: 5100A‐5XACULCX
The RADWIN SU PRO/AIR EMB must be installed so as to provide a minimum separaon distance from
bystanders as specied in the tables below.
This radio transmier “IC: 5100A‐5XACULCX” has been approved by Innovaon, Science and Economic
Development Canada to operate with the antenna types listed below, with the maximum permissible gain
indicated. Antenna types not included in this list that have a gain greater than the maximum gain indicated
for any type listed are strictly prohibited for use with this device.
The input impedance of all antennas is 50 Ohm.
Table 14: Frequency Band 5725‐5850 MHz
Cat. No.
Type
Gain (dBi)
Dir BW
Tx Power per
chain (dBm)
Min. Safe
Distance (cm)
Embedded
Flat DB
16.0
17.5° Hor
29.1° Ver
27
110
RW‐9614‐5359
Flat DB
23.0
10.0°
27
110
Table 15: Frequency Bands 5250‐5350 MHz and 5470‐5725 MHz
Cat. No.
Type
Gain (dBi)
Dir BW
Tx Power per
chain (dBm)
Min. Safe
Distance (cm)
Embedded
Flat DB
16.0
17.5° Hor
29.1° Ver
10
20
RW‐9614‐5359
Flat DB
23.0
10.0°
4
20
Table 16: Frequency Band 5150‐5250 MHz

Radwin 5000 Specifications

General

Channel Bandwidth	5 MHz, 10 MHz, 20 MHz, 40 MHz
Encryption	AES
Product Type	Point-to-Point
Interface	Ethernet
Frequency Bands	5.1 GHz, 5.4 GHz, 5.8 GHz
Modulation	Adaptive Modulation (QPSK to 256QAM)
