Radwin 5000 Installation Guide

RADWIN 5000 Installaon Guide
August 2023
114
Operang Form
Gain (dBi)
Dir BW
Tx Power per
chain (dBm)
Min. Safe
Distance (cm)
Uniform
17.0
17°
27
55
Floodlight
9.0
70°
27
55
The JET‐DUO 5.x/5.x GHz bears the following FCC/IC IDs on the label, and refer to Table 26 to Table 27
below:
FCC ID: Q3K‐JETDC5X5X IC: 5100A‐JETDC5X5X
This radio transmier “IC: 5100A‐JETDC5X5X” has been approved by Innovaon, Science and Economic
Development Canada to operate with the antenna types listed below, with the maximum permissible gain
indicated. Antenna types not included in this list that have a gain greater than the maximum gain indicated
for any type listed are strictly prohibited for use with this device.
The input impedance of all antennas is 50 Ohm.
The JET‐DUO 5.x/5.x GHz must be installed so as to provide a minimum separaon distance from bystanders
as specied in the tables below:
Table 26: Frequency Band 5725‐5850 MHz
Operang Form
Gain (dBi)
Dir BW
Tx Power per
chain (dBm)
Min. Safe
Distance (cm)
Uniform
19.0
19°
14
20
Floodlight
9.0
80°
24
20
Table 27: Frequency Band 5150‐5250 MHz (FCC only)
Operang Form
Gain (dBi)
Dir BW
Tx Power per
chain (dBm)
Min. Safe
Distance (cm)
Uniform
17.0
18°
16
20
Floodlight
7.0
80°
26
20
The MulSector Base Staon bears the following FCC/IC IDs on the label, and refer to Table 28 below:
Contains FCC ID: Q3K‐5XACMODMS Contains IC: 5100A‐5XACMODMS
This radio transmier ”Contains IC: 5100A‐5XACMODMS” has been approved by Innovaon, Science and
Economic Development Canada to operate with the antenna types listed below, with the maximum
permissible gain indicated. Antenna types not included in this list that have a gain greater than the
maximum gain indicated for any type listed are strictly prohibited for use with this device.
The input impedance of all antennas is 50 Ohm.

Radwin 5000 Specifications

General

Channel Bandwidth	5 MHz, 10 MHz, 20 MHz, 40 MHz
Encryption	AES
Product Type	Point-to-Point
Interface	Ethernet
Frequency Bands	5.1 GHz, 5.4 GHz, 5.8 GHz
Modulation	Adaptive Modulation (QPSK to 256QAM)
