RADWIN5000ConfigurationGuide Release4.9.17 4‐48
ConfigurationMenuButtons ManagingtheSector
• TheAutopositionmeansthattheBuzzerwillbeepasshowninFigure 4‐24during
installationoruponsyncloss.ThemainuseofthebuzzertoneisforHSUantenna
alignment.
• TheAdvancedAutopositionmeansthatthebuzzerwillbeepcontinuouslyatdif‐
ferentratesuponsyncloss,antennamis‐alignmentandothereventsforuptotwo
minutesfollowingrestorationofsync.
Figure4‐24:Antennabeepsequence
TheRefreshbuttonrestoresthecurrentwindowtoitspreviousstateabandoninganychanges
youmade,providedthatyoudidnotclickApplyorOK.
WewillworkthrougheachoftheConfigurationtabsinturn:
Abackup(fullorconfiguration)mayberestoredtopanotherHSUprovidedthatthe
productIDsandrevisionlevelsofthesourceandtargetHSUsareidentical.
Inaddition,thecapacityandsupportedbandsmustbethesameforthesourceand
restoredHSUs.

Radwin 5000 Specifications

General

Channel Bandwidth	5 MHz, 10 MHz, 20 MHz, 40 MHz
Encryption	AES
Product Type	Point-to-Point
Interface	Ethernet
Frequency Bands	5.1 GHz, 5.4 GHz, 5.8 GHz
Modulation	Adaptive Modulation (QPSK to 256QAM)
